Drawing Canvas

Align Multiple Symbols


Enhanced Object Selection

Window Selection (L-R - Blue): Includes all objects that are entirely enclosed in the selection rectangle.
Crossing Selection (R-L - Green): Includes all objects that are intersected by the selection rectangle.

Connection Points Maintained on the Grid

Symbol automatically relocates to the nearest grid point after the Rotation or Flip command is run, such that the connection points lie on the grid.

Clear Distinction Between Drawing Mode and Symbol Build Mode

In the Symbol Build Mode, an orange strip displays along with an Exit Symbol Build Mode button in the top right corner.


Improved Zoom Behavior

Improved precision during zoom in/out operations.

Smarter Context Menu for Envelope

Context Menu commands will now appear only when an envelope is selected and not when its Item ID is selected.

Bug Resolved

User prompted to save drawing when logging out after a previous active session.
